Growatt MIN 2500TL-X User Manual

33
6.8 Inverter demand response modes (DRMS)
This series inverter has the function of demand response modes, We use 8Pin socket
as inverter DRMS connection.
Information
DRMS application description
 Only applicable to AS/NZS4777.2:2015.
 DRM0, DRM5, DRM6, DRM7, DRM8 are available.
CAUTION
Damage to the inverter due to moisture and dust penetration
 Make sure the cable gland has been tightened firmly.
 If the cable gland are not mounted properly, the inverter can
be destroyed due to moisture and dust penetration. All the
warranty claim will be invalid.
6.8.1 8Pin socket pin assignment
Pin
Assignment for inverters capable
of both charging and discharging
1
DRM 5
2
DRM 6
3
DRM 7
4
DRM 8
5
RefGen
6
Com/DRM0
7
NC
8
NC
6.8.2 Method of asserting demand response modes
Mode
Socket Asserted
by shorting pins
Requirement
DRM 0
5
6
Operate the disconnection device
DRM 5
1
5
Do not generate power
DRM 6
2
5
Do not generate at more than 50% of rated power
DRM 7
3
5
Do not generate at more than 75% of rated power
AND Sink reactive power if capabie
DRM 8
4
5
Increase power generation (subject to constraints from
other active DRMs)
7 Commissioning

Growatt MIN 2500TL-X Specifications

General

Product color	White
Overvoltage category	CAT II
Power protection features	Over voltage, Reverse polarity, Short circuit
International Protection (IP) code	IP65
Noise level	35 dB
Product type	-
Maximum power	2500 W
Output current	13.3 A
DC input voltage	500 V
Number of phases	1
Output frequency	50/60 Hz
Starting voltage	100 V
MPP voltage range	80 - 500 V
Output power capacity (max)	- kVA
Input operation voltage (min)	80 V
Output operation voltage (max)	280 V
Output operation voltage (min)	180 V
Operating temperature (T-T)	-25 - 60 °C
Wi-Fi	Yes
Display technology	OLED

Weight and Dimensions

Depth	160 mm
Width	375 mm
Height	350 mm
Weight	10800 g
