Growatt MIN 2500TL-X User Manual

49
unit
General data
Dimensions (W / H / D) in mm
375*350*160
Weight
10.8 kg
Operating temperature range
–25 °C ... +60 °C
Noise emission (typical)
≤ 25 dB(A)
Altitude
4000m
Internal consumption at night
<1W
Topology
transformerless
Cooling
Natural convection
Protection degree
IP65
Relative humidity
0~100%
DC connection
VP-D4/MC4(Optional)
AC connection
AC connector
Interfaces
Display
OLED+LED
RS485/USB
Integrated
WIFI/GPRS/4G/LAN/ RF
Optional
Warranty:5/10 years
Yes/ Optional
13.2 DC &AC connector info
DC connector
VP-D4/ MC4(opt)
AC connector
M-S30_SD03_S10 001U-A
VPAC06EP-3S(SC)5
VPAC06EW-3P(SC)
13.3 Torque
Enclosure lid screws
12kg.cm
AC terminal
6kg.cm
Signal terminal
4kg.cm
Safety screw
12kg.cm
Additional ground screws
12kg.cm
13.4 Accessories
In the following table you will find the optional accessories for your product. If
required, you can order these from GROWATT NEW ENERGY TECHNOLOGY

Growatt MIN 2500TL-X Specifications

General

Product color	White
Overvoltage category	CAT II
Power protection features	Over voltage, Reverse polarity, Short circuit
International Protection (IP) code	IP65
Noise level	35 dB
Product type	-
Maximum power	2500 W
Output current	13.3 A
DC input voltage	500 V
Number of phases	1
Output frequency	50/60 Hz
Starting voltage	100 V
MPP voltage range	80 - 500 V
Output power capacity (max)	- kVA
Input operation voltage (min)	80 V
Output operation voltage (max)	280 V
Output operation voltage (min)	180 V
Operating temperature (T-T)	-25 - 60 °C
Wi-Fi	Yes
Display technology	OLED

Weight and Dimensions

Depth	160 mm
Width	375 mm
Height	350 mm
Weight	10800 g
