8. Dimensions
PNEG-2381
2000 Series U-T
rough Bin Sweep Aug
er Unload System (72' - 78')
49
Gate Dimensions
Figure 8B
Ref #
Description
2
Center of t
he Bin
6
Bin Centerline
7
T
rough Centerline
8
Minimum clearance require
d between the bin wall
and outer gate for t
he elevator wheel.
48
50
