Standard Operations
5.12.3 Profibus/Modbus configuration example
Table 17 and Table 18 show a Profibus/Modbus configuration example.
For more information concerning Profibus configuration settings, refer to section 6.3.4.1
on page 109.
For more information concerning Modbus configuration settings, refer to section 6.3.4.2
on page 111.
Table 17 Profibus configuration example
Profibus
address
Slave Byte Device Data name
5 Configured Slave
1,2
AMTAX SC
ERROR
3,4 STATUS
5,6,7,8 CUVETTE TEMP
9,10,11,12 MEASURED VALUE 1
13,14
mA INPUT INT
ERROR
15,16, STATUS
17,18,19,20 INPUT CURRENT 1
21,22 DIGITAL INPUT 2
23,24,25,26 OUTPUT VALUE 3
27,28 DIGITAL INPUIT 4
Table 18 Modbus configuration example with virtual slaves
Modbus
address
Slave Register Device Data name
5 Configured Slave
40001
AMTAX SC
ERROR
40002 STATUS
40003 CUVETTE TEMP
40005 MEASURED VALUE 1
40007
mA INPUT INT
ERROR
40008 STATUS
40009 INPUT CURRENT 1
40011 DIGITAL INPUT 2
40012 OUTPUT VALUE 3
40014 DIGITAL INPUIT 4
6
First virtual slave
(AMTAX SC)
40001
AMTAX SC (complete)
See AMTAX SC profile
40002 See AMTAX SC profile
... See AMTAX SC profile
7
Second virtual slave
(mA INPUT INT)
40001
mA INPUT INT (complete)
See mA INPUT INT profile
40002 See mA INPUT INT profile
... See mA INPUT INT profile
