Hantek DSO2000 Series User Manual

56 / 72
Persist
Off
Display Mode
YT
Horizontal
Window Mode
Single-window
Trigger Knob
Level
Position
0.00s
SEC/DIV
200μs
Math
Status
Off
Measure
Status
Off
Trigger (Edge)
Type
Edge
Source
CH1
Slope
Rising
Mode
Auto
Level
0.00v
Vertical System,
All Channels
Bandwidth Limit
Unlimited
VOLTS/DIV
Coarse
Probe Attenuation
1X
Invert
Off
Position
0.00div (0.00V)
VOLTS/DIV
1V
The following settings do not change when you push the [Default] button.
➢ Language Option
➢ Saved Settings
➢ Saved Reference waveform
➢ Display Contrast
➢ Calibration Data
2.15.3. Dual-window Mode
Press the Sec/DIV knob to enter the dual-window mode, and press the button again to exit the
dual-window mode.
Single-window Mode
