8 - Technical specifications
8.3
Filters and nozzles
Filter gauze width
30 mesh: 0.58 mm
50 mesh: 0.30 mm
80 mesh: 0.18 mm
100 mesh: 0.15 mm
Temperature and pressure ranges
Spray liquid:
Operating temperature range: 36° F to 104° F (2° to 40° C )
Operating pressure for safety valve: 220 psi (15 bar)
Max. pressure on the pressure manifold: 290 psi (20 bar)
Max. pressure on the suction manifold: 100 psi (7 bar)
Tire pressure
€
DANGER! Never inflate tires more than to the pressure specified in the table. Over-inflated tires can explode and cause
severe personal injuries! See the part “Occasional maintenance - Change of tire”.
Tire size Rec. inflation pressure in p.s.i. (bar)
11.2 x 38 35 (2.4)
