User Manual of Network Speed Dome
© Hikvision
109
Configuration> Advanced Configuration> Security > Authentication
Figure 10-4 RTSP Authentication
2. Set the authentication mode for each authentication type.
RTSP Authentication: Select the authentication mode as basic or disable in
the dropdown list to enable or disable the RTSP authentication.
WEB Authentication: Select the authentication mode as basic or digest in
the dropdown list.
3. Click to save the settings.
10.3 Configuring Anonymous Visit
When you enable this function, you can log into the camera without a username and
password.
In login interface, check the Anonymous checkbox and click Login to enter the
camera as shown in Figure 10-6.
Figure 10-5 Anonymous Login
Figure 10-6 Login Interface
10.4 Configuring IP Address Filter
With this function on, the camera allows certain IP addresses whether to log in or
not.
Filter Type
Description
Forbidden
Forbid the IP addresses added in the IP Address
Filter interface to log in.

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the HIKVISION DS-2DF5286-AEL and is the answer not in the manual?

HIKVISION DS-2DF5286-AEL Specifications

General IconGeneral
TypeIP security camera
PTZ controlYes
Placement supportedOutdoor
Connectivity technologyWired
Form factorDome
Mounting typeWall
Product colorWhite
International Protection (IP) codeIP66
Total megapixels2 MP
Maximum resolution1920 x 1080 pixels
Supported video modes1080p, 720p
Video formats supportedH.264, MPEG4
Supported graphics resolutions1280 x 960, 1280 x 720 (HD 720), 1920 x 1080 (HD 1080)
Pan range0 - 360 °
Pan speed300 °/sec
White balanceATW, Auto, Indoor, Lamp, Manual, Outdoor
Tilt angle range-5 - 90 °
Camera shutter speed1 - 1/10000 s
Minimum illumination0.03 lx
Field of view (FOV) angle58.9 °
Sensor typeCMOS
Optical sensor size1/2.8 \
Digital zoom16 x
Optical zoom30 x
Focal length range- mm
Password protection typeUser
Built-in HDD-
Compatible memory cardsMicroSD (TransFlash)
Maximum memory card size32 GB
LED typeIR
Wi-FiNo
Cabling technology10/100Base-T(X)
Supported network protocolsIPv4/IPv6, HTTP, HTTPS, 802.1x, Qos, FTP, SMTP, UPnP, SNMP, DNS, DDNS, NTP, RTSP, RTP, TCP/IP, UDP, IGMP, ICMP, DHCP, PPPoE
Ethernet LAN (RJ-45) ports1
Signal-to-Noise Ratio (SNR)52 dB
AC input voltage24 V
Power source typePoE
Power consumption (max)65 W
Operating temperature (T-T)-40 - 65 °C
Operating relative humidity (H-H)0 - 90 %
Weight and Dimensions IconWeight and Dimensions
Height305 mm
Weight5000 g
Diameter220 mm
