7.2 Initializing and Configuring Storage
Steps:
1. Initialize the local disk or added network disk.
(1) Enter the HDD Settings interface (Advanced Configuration > Storage >
Storage Management), in which you can view the capacity, free space, status,
type and property of the disk.
(2) If the status of the disk is Uninitialized as shown in Figure 7-3, check the
corresponding checkbox to select the disk and click to start
initializing the disk.
Figure 7-3 Initialize Disk
Figure 7-4 Initializing
When the initialization completed, the status of disk will become Normal as
shown in Figure 7-5.
Figure 7-5 View Disk Status
2. Configure the quota for saving the video and picture.
Enter the percentage for picture and record in the text filed, and the total
percentage must be 100%.
Figure 7-6 Setting Quota
To Next Page
