configuration is the same as the setting of the arming schedule for motion
detection. Refer to Step 2 in Section 6.6.1 Configuring Motion Detection.
7. Check the checkbox to select the linkage method taken for the intrusion
detection. Notify surveillance center, send email, trigger channel, smart tracking
and trigger alarm output are selectable. Please refer to Step 3 in Section 6.6.1
Configuring Motion Detection.
8. Click to save the settings.
6.6.10 Configuring Line Crossing Detection
The virtual plane detection can be adopted for the intrusion detection. Once the
virtual plane is detected being traversed according to the configured direction, a set
of alarm action is triggered.
Steps:
1. Enter the Line Crossing Detection interface:
Configuration > Advanced Configuration > Events > Line Crossing Detection
2. Check the Line Crossing Detection checkbox.
3. Select the Line in dropdown list to configure.
4. The event triggered and park action related PTZ movement will be locked for 180
seconds after you enter the line crossing detection interface. Optionally, you can
click the button to manually activate the movement, or lock the
movement when the button turns to by clicking it.
