Page #224 background imageLoading...
Page #224 background image
Network Video Recorder User Manual
223
Figure 1. 2 Array Settings Interface
If there is no hot spare disk after rebuilding, it is recommended to install a HDD into the device and
set is as a hot spare disk to ensure the high security and reliability of the array.
13.2.3 Manually Rebuilding Array
Purpose:
If the hot spare disk has not been configured, you can rebuild the array manually to restore the
array when the virtual disk is in Degraded status.
Step 1 Enter the Array Settings interface. The disk 3 is lost.
Menu > HDD > RAID > Array
Figure 13-11 Array Settings Interface
Step 2 Click Array tab to back to the Array Settings interface and click to configure the array
rebuild.
At least one available physical disk should exist for rebuilding the array.

Table of Contents

Other manuals for HIKVISION DS-9632NI-I16

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the HIKVISION DS-9632NI-I16 and is the answer not in the manual?

HIKVISION DS-9632NI-I16 Specifications

General IconGeneral
Input bandwidth320 Mbit/s
Output bandwidth256 Mbit/s
Maximum resolution3840 x 2160 pixels
Alarm input channels16
Video input channels32 channels
Alarm output channels8
Supported resolutions3840 x 2160, 3840 x 2160, 2560 x 1440, 1920 x 1080, 1600 x 1200, 1280 x 1024, 1280 x 720, 1024 x 768
Video recording modes1080p, 2160p
Video formats supportedH.264, H.264+, H.265, MPEG4
Audio RCA inputs1
USB 2.0 ports quantityUSB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN data rates10, 100, 1000 Mbit/s
Power over Ethernet (PoE)Yes
Ethernet LAN (RJ-45) ports2
Wi-FiNo
HDD capacity0 GB
HDD interfaceSerial ATA
Maximum storage capacity96 TB
Number of HDDs installed0
Power supply300 W
AC input voltage100 - 240 V
AC input frequency50 - 60 Hz
Power consumption (typical)45 W
Operating temperature (T-T)-10 - 55 °C
Operating relative humidity (H-H)10 - 90 %
Product colorBlack
Rack capacity3U
Weight and Dimensions IconWeight and Dimensions
Depth496 mm
Width445 mm
Height146 mm
Weight12500 g
