HIKVISION DS-9632NI-I16 User Manual

Network Video Recorder User Manual
269
18.1.2 DS-9600NI-I16
Model
DS-9616NI-I16
DS-9632NI-I16
DS-9664NI-I16
Video/Aud
io input
IP video input
16-ch
32-ch
64-ch
Incoming
bandwidth
256 Mbps
320 Mbps
320 Mbps
Or 200 Mbps (when RAID is enabled)
Outgoing
bandwidth
256 Mbps, or 200 Mbps (when RAID is enabled)
Video/Aud
io output
VGA1 /HDMI1
output
resolution
VGA1: 2K (2560 × 1440)/60Hz, 1920 × 1080/60Hz, 1280 ×
1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz
HDMI1: 4K (3840 × 2160)/60Hz, 4K (3840 × 2160)/30Hz, 2K
(2560 × 1440)/60Hz, 1920 × 1080/60Hz, 1600 × 1200/60Hz,
1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz
VGA2 /HDMI2
output
resolution
VGA2: 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 ×
720/60Hz, 1024 × 768/60Hz
HDMI2: 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 ×
720/60Hz, 1024 × 768/60Hz
Audio output
2-ch, RCA (Linear, 1 KΩ)
Decoding
Decoding format
H.265/H.265+/H.264/H.264+/MPEG4
Recording
resolution
12 MP/8 MP/6 MP/5 MP/4 MP/3 MP/1080p/UXGA
/720p/VGA/4CIF/DCIF/2CIF/CIF/QCIF
Synchronous
playback
16-ch
Capability
2-ch @ 12 MP (20fps) / 4-ch @ 8 MP (25fps) / 8-ch @ 4MP
(30fps) / 16-ch @ 1080p (30fps)
Network
managem
ent
Network
protocols
TCP/IP, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, SMTP,
NFS, iSCSI, UPnP™, HTTPS
Hard disk
SATA
16 SATA interfaces
eSATA
1 eSATA interface
Capacity
Up to 6 TB capacity for each disk
Disk array
Array type
RAID 0, RAID 1, RAID 5, RAID 6, RAID 10
External
interface
Two-way audio
1-ch, RCA (2.0 Vp-p, 1 k Ω)
Network
2, RJ-45 10/100/1000 Mbps self-adaptive Ethernet interface

HIKVISION DS-9632NI-I16 Specifications

General

Input bandwidth	320 Mbit/s
Output bandwidth	256 Mbit/s
Maximum resolution	3840 x 2160 pixels
Alarm input channels	16
Video input channels	32 channels
Alarm output channels	8
Supported resolutions	3840 x 2160, 3840 x 2160, 2560 x 1440, 1920 x 1080, 1600 x 1200, 1280 x 1024, 1280 x 720, 1024 x 768
Video recording modes	1080p, 2160p
Video formats supported	H.264, H.264+, H.265, MPEG4
Audio RCA inputs	1
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Power over Ethernet (PoE)	Yes
Ethernet LAN (RJ-45) ports	2
Wi-Fi	No
HDD capacity	0 GB
HDD interface	Serial ATA
Maximum storage capacity	96 TB
Number of HDDs installed	0
Power supply	300 W
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (typical)	45 W
Operating temperature (T-T)	-10 - 55 °C
Operating relative humidity (H-H)	10 - 90 %
Product color	Black
Rack capacity	3U

Weight and Dimensions

Depth	496 mm
Width	445 mm
Height	146 mm
Weight	12500 g
