Fingerprint Time Attendance Terminal
77
4. Click the radio button of card linkage, and input the card number.
5. Select the event source, and check the checkbox of the card reader’s serial
number.
6. Set the linkage target, and set the property as Trigger to enable this function.
Controller Buzzer: The audible warning of controller will be triggered.
Snapshot: The real-time capture will be triggered.
Reader Buzzer: The audible warning of card reader will be triggered.
Alarm Output: The alarm output will be triggered for notification.
Door: The door status of open, close, normally open, and normally close will be
triggered.
7. Click the button to save parameters.
8. Click the Apply button to download the updated parameters to the local memory
of the device.
Note: The door status of open, close, normally open, and normally close cannot be
triggered at the same time.
4.3.6 Access Permission Configuration
Click the icon on the control panel to enter the interface.
