UART No. Related Terminals Terminal Posion DIP Switch No. Funcon
Note
External card
reader is
recommended to
access.
4 to 6 ON: UART3 is RS-
485C Interface
485C-/232C- 7 Reserved
8 Reserved
UART5
Note
External card
reader is
recommended to
access.
485E+/232E+ BUS of Sub Lane
Control Board
1 to 3 ON: UART3 is RS-
232E Interface
4 to 6 ON: UART3 is RS-
485E Interface
485E-/232E- 7 Reserved
8 Reserved
UART6
Note
Face recognion
terminal is
recommended to
access.
485F+/232F+ BUS of Sub Lane
Control Board
1 to 3 ON: UART3 is RS-
232F Interface
4 to 6 ON: UART3 is RS-
485F Interface
485F-/232F- 7 Reserved
8 Reserved
UART7 232G+/232G- Access Control
Board
/ /
UART8 232H+/232H- Access Control
Board
/ /
4.5.2 Main Control Board Terminal Descripon
The main lane control board contains power input, BUS interface, interconnecng interface,
supercapacitor interface, barrier
posion control board interface and motor drive interface.
The picture displayed below is the main control board diagram.
DS-K3Y411X Series Flap Barrier Quick Start Guide
17
