Chapter 5 Device Sengs

Aer installaon and wiring completed, the turnsle will learn the open and closed posion

automacally.

Aer

the learning, the turnsle is in the normal mode. You can also set the turnsle to test mode,

passing mode and memory mode, pair the keyfob, inialize the hardware, switching between

RS-485

communicaon mode and RS-232 communicaon mode, and view relay output NO/NC

diagram by seng the DIP switch on the access control board.

• Normal Mode: The device will work properly.

• Test Mode: Test mode is the same as the normal mode except that the device cannot report the

alarm, the event, or the people

counng informaon to the center.

• Passing Mode: There are 9 passing modes, including controlled

bi-direcon, controlled entrance

and prohibited exit, controlled entrance and free exit, free bi-direcon, free entrance and

controlled exit, free entrance and prohibited exit, prohibited

bi-direcon, prohibited entrance

and free exit.

• Memory Mode: By default, the memory mode is enabled. When mulple cards are presented

and authencated, it allows mulple persons passing through the lane. When it counts the

passing people number is equal to the card presented

mes, or no person passing through the

lane aer the last person passing, the barriers will be closed.

Note

You can also set the DIP switch on the access control board to control the entrance and exit

controlling type, keyfob pairing, etc. For details about the DIP switch value, see Access Control

Board UART Descripon .

5.1 Pair Keyfob (Oponal)

Pair the remote control to the device through DIP switch to open/close the barrier remotely.

Before You Start

Ask our technique supports or sales and purchase the keyfob.

Steps

Note

• Up to 32 keyfobs can be added to the

turnsle.

• You can set the keyfob to one-to-one mode or one-to-many mode via the DIP switch on the

keyfob. Here takes one-to-one mode as an example to explain. For one-to-many mode, see the

keyfob user manual.

One-to-One Mode
