15. Power Saving Details Setting
A16381TMF2
31
This function provides the details for setting the power savings function.
For the "Mode", select one item from each of the following settings, (1) outdoor unit capacity control, (2) indoor
unit rotation control, and (3) intermittent control.
NOTE:
•
Go to Power Savings Setting from Function Menu. Also refer to "Power Savings Setting" in the Operation
Manual for details.
15. Power Saving Details Setting
1. Outdoor Unit Capacity Control Setting
Step1. Select "Service Menu" on the Service & Installation screen
and press "OK".
Step2. Select "Power Saving Details Setting" and press "OK".
Step3. Select "Capacity Control"
and press "OK".
Step4. Press " " or " ".
The items "Control"
↔
"Sav: Low"
↔
"Sav: Med"
↔
"Sav: High" are displayed in order.
Press " " to move to Step7.
Step5. Change the Control Method
Select "Control" and press "OK".
Press " " or " " to select the item to set and press "OK".
It changes between "Peak Cut Control" and "Moderate
Control".
Press " " to return to Step4.
Step6. Change the power savings level
Select "Sav: Low(Med/High)" and press "OK".
Press " " or " " to set the level.
→ The level changes as follows:
[100%]
↔
[90%]
↔
[80%]
↔
[70%]
↔
[60%]
↔
[50%]
↔
[40%]
↔
[0%].
After setting, select "
" and press "OK" and it returns to Step3.
Item Function
Capacity Control
Suppress the heating and cooling capacity of the indoor unit.
Set control mode and power savings level with its corresponding value.
Rotation Control
Interlock with indoor units of the same outdoor unit system and switch to FAN operation
in sequence.
Set control mode and fan mode time.
Intermittent Control
Cooling/heating mode and fan mode are repeated at regular intervals.
Set power savings level.
Reset Default Initialize the power saving details settings.
(1) Outdoor Capacity Control Setting
Item Description
Control Method
The "Peak Cut Control" reduces the power consumption range when it exceeds the value
of the power setting. On the basis of the current air conditioning capacity, the
"Moderate Control" is used to moderate the air conditioning capacity as well as the peak.
Power Savings Low (Med/High)
Assign the corresponding capacity control values to the low, medium, and high power
savings levels.
Change Level The power saving details setting can change the power savings levels.
Power Saving Details Setting
Intermittent Control
Reset Default
Rotation Control
Capacity Control
OK
Select Back
Capacity Control
Control
Sav: Low
Sav: Med 80%
Sav: High 60%
Peak Cut Control
Operate in power set value range.
OK
Select Back
100%
:
:
:
:
Capacity Control
Peak Cut Control
Moderate Control
Select setting range of power savings.
OK
Select Back
Sav: Low
50%
OK
Back
To Next Page
