15.3. Electrical Data
Model
Unit main power
Applicable
Instantaneous
Voltage (V)
Commpressor
Motor
Maximum
Unit
Current
STC
*2
Unit
Maximum
STC
*1
(A)
RNC
(A)
IPT
(kW)
(V) (Hz) Maximum Minimum (A) (A)
RCUE40CLG2
380 50 418 342 114 59.4 34.4 93 114
400 50 440 360 121 56.4 34.4 88 121
415 50 457 374 125 54.4 34.4 85 125
RCUE50CLG2
380 50 418 342 148 73.2 42.4 114 148
400 50 440 360 155 69.5 42.4 108 155
415 50 457 374 161 67.0 42.4 105 161
RCUE60CLG2
380 50 418 342 178 90.0 52.1 140 178
400 50 440 360 188 85.5 52.1 133 188
415 50 457 374 195 82.4 52.1 128 195
RCUE80CLG2
380 50 418 342 114 118.8 68.8 185 134
400 50 440 360 121 112.8 68.8 176 140
415 50 457 374 125 108.8 68.8 170 143
RCUE100CLG2
380 50 418 342 148 146.4 84.8 228 172
400 50 440 360 155 139.1 84.8 217 178
415 50 457 374 161 134.1 84.8 209 183
RCUE120CLG2
380 50 418 342 178 179.9 104.2 281 208
400 50 440 360 188 170.9 104.2 267 216
415 50 457 374 195 164.7 104.2 257 222
VOL: Rated Unit Supply Voltage(V) RNC: Running Current(A)
STC: Starting Current(A) IPT: Input(kW)
Hz: Frequency(Hz)
 NOTE:
1. This data is based on the following conditions. Chilled Water Inlet/Outlet Temperature: 12/7°C, Condensing Temperature: 45°C.
2. The “Maximum Unit Current” shown in the above table is the maximum total unit running current at the following conditions.
Supply Voltage: 90% of the rated voltage, Unit Capacity: 100% at max. operating conditions
3. The power supply cables must be sized to cover this maximum current value.
4. Starting Current (*1,*2) means as follows.
*
1
:First Compressor Starting Current
*
2
:Unit Maximum Starting Current, when Last Compressor starts.
5. Compressor motor is star-delta starting.
