Drawings
Technical Catalogue
TCGB0051 rev 0 - 09/2009
88
14.1. Dimensional Drawings
14.1.1. RCUE40CLG2
14.1.2. RCUE50CLG2
Inlet for power
supply wiring
Cooler Water Inlet
4x Lifting Holes
Cooler Water Outlet
0 (welding connection)
54 (3B Victaulic
connection)
Electrical Box
Inlet for control
wiring
Inlet for power
supply wiiring
Cooler Water Inlet
4x Lifting Holes
Cooler Water Outlet
0 (welding connection)
54 (3B Victaulic
connection)
Electrical Box
Inlet for control
wiring
