17.1. Compressor
Model 40ASC-Z 50ASC-Z 60ASC-Z
Type Semi-Hermetic
Revolution rpm 2880
Displacement m
3
/h 137.4 169.5 208.7
Capacity Control % 100 ~ 15, 0
Pneumatic Pressure
High Side MPa 3.0
Low Side MPa 2.0
Motor Type Special Squirrel Cage, Three-Phase Motor
Starting Method Star-Delta Starting
Nominal Output kW 30 37 45
Poles 2
Insulation E
Oil Name JAPAN ENERGY, FREOL UX300
Charge L 6
Net Weight kg 400 440 460
17.2. Water Cooler
Model RCUE-CLG2 40 50 60 80 100,120
Water Cooler Brazed Type Plate Heat Exchanger
Type (Quantity)
See Table Below
A(1) B(1) C(1) D(1) E(1)
TYPE
SINGLE TYPE DUAL TYPE
A B C D E
REFRIGERANT CYCLE 40HP 50HP 60HP 80HP (100/120)HP
Dimensions
Height (H) mm 525 525 525 694 694
Width (W) mm 243 243 243 304 304
Depth (D) mm 271 299 381 380 476
Maximum Permissible Pressure
Refrigerant Side MPa 1.8 1.8 1.8 1.8 1.8
Water Side MPa 1.0 1.0 1.0 1.0 1.0
Internal Volume
Refrigerant Side L 13.5 14.9 19.3 2x15.4 2x19.5
Water Side L 13.7 15.2 19.5 32.4 40.8
Material Stainless Steel
Approval PED (1)
NOTE:
Pressure equipment Directive (97/23/EC)
