13-4
Model ZW180 ZW220 ZW250 ZW310
Bucket Type
RB3210-63F RB3240-63G RB3280-63H RB3340-63J
Bucket Capacity : heaped
m
3
2.1 2.4 2.8 3.2
Bucket Capacity : Struck
m
3
1.8 2.0 2.4 2.8
Operating Weight
kg 14830 18180 20700 23700
Tipping Load
kg 11440 12600 13750 16500
A: Overall Length
mm 7630 8200 8435 8890
B: Overall Width (Bucket)
mm 2535 2910 2980 —
C: Overall Height
mm 3285 3370 3400 3460
D: Bucket Hinge Height
mm 3920 4085 4190 4390
E: Dumping Clearance (45°)
mm 2790 2910 2920 3040
F: Dumping Reach (45°)
mm 1120 1120 1180 1290
R1: Minimum Rotation Radius
mm 6040 6600 6760 6930
NOTE: These specifications are subject to change without notice.
M4GB-13-002
