Honda ADV150 2019 User Manual

Side Stand
Checking the Side Stand
1. Place your vehicle on its centre stand on a
firm, level surface.
2. Check that the side stand operates
smoothly. If the side stand is stiff or
squeaky, clean the pivot area and
lubricate the pivot bolt with clean grease.
3. Check the spring for damage or loss of
tension.
4. Sit on the vehicle and raise the side stand.
5. Start the engine.
6. Lower the side stand all the way. The
engine should stop as you lower the side
stand. If the engine doesn't stop, have
your vehicle inspected by your dealer.
20191017191217_32K0WC000_eng_BOOK Page 100 Thursday, October 17 2019 19:17:25 JST
Maintenance
97
Side stand
spring

Honda ADV150 2019 Specifications

General

Displacement	149.3 cc
Bore x Stroke	57.3 mm x 57.9 mm
Compression Ratio	10.6:1
Fuel System	PGM-FI (Programmed Fuel Injection)
Ignition System	Full Transistorized Ignition
Starting System	Electric
Front Suspension	Telescopic Fork
Front Brake	Hydraulic Disc
Rear Brake	Mechanical Drum
Front Tire	110/80-14
Rear Tire	130/70-13
Length	1, 950 mm
Width	763 mm
Height	1, 153 mm
Seat Height	795 mm
Wheelbase	1, 324 mm
Ground Clearance	165 mm
Curb Weight	133 kg
Engine Type	Liquid-cooled, 4-stroke, SOHC
Transmission	Automatic, V-Matic
Rear Suspension	Twin Shock
Fuel Tank Capacity	8.0 L
