Honda ADV150 2019 User Manual

Blown Fuse
Before handling fuses, see “Inspecting and
Replacing Fuses.” 2 P. 74
#
Fuse Box Fuses
1. Remove the battery cover. 2 P. 83
2. Open the fuse box cover.
3. Pull the main fuse and other fuses out
one by one with the fuse puller located
inside of the fuse box cover. Check for a
blown fuse. Always replace a blown fuse
with a spare fuse of the same rating.
4. Install the fuse box cover.
5. Install the battery cover.
NOTICE
If a fuse fails repeatedly, you likely have an
electrical problem. Have your vehicle inspected
by your dealer.
20191017191217_32K0WC000_eng_BOOK Page 127 Thursday, October 17 2019 19:17:25 JST
Electrical Trouble u Blown Fuse
Troubleshooting
124
Fuse box
cover
Fuse puller
Spare fuses
Main fuse A
Main fuse B

Honda ADV150 2019 Specifications

General

Displacement	149.3 cc
Bore x Stroke	57.3 mm x 57.9 mm
Compression Ratio	10.6:1
Fuel System	PGM-FI (Programmed Fuel Injection)
Ignition System	Full Transistorized Ignition
Starting System	Electric
Front Suspension	Telescopic Fork
Front Brake	Hydraulic Disc
Rear Brake	Mechanical Drum
Front Tire	110/80-14
Rear Tire	130/70-13
Length	1, 950 mm
Width	763 mm
Height	1, 153 mm
Seat Height	795 mm
Wheelbase	1, 324 mm
Ground Clearance	165 mm
Curb Weight	133 kg
Engine Type	Liquid-cooled, 4-stroke, SOHC
Transmission	Automatic, V-Matic
Rear Suspension	Twin Shock
Fuel Tank Capacity	8.0 L
