Throttle
Checking the Throttle
With the engine off, check that the throttle
rotates smoothly from fully closed to fully
open in all steering positions and throttle
freeplay is correct. If the throttle does not
move smoothly, close automatically, or if the
cable is damaged, have the vehicle inspected
by your dealer.
Freeplay at the throttle grip flange:
2 - 6 mm (0.1 - 0.2 in)
20191017191217_32K0WC000_eng_BOOK Page 101 Thursday, October 17 2019 19:17:25 JST
Maintenance
98
Freeplay
Flange

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Honda ADV150 2019 and is the answer not in the manual?

Honda ADV150 2019 Specifications

General IconGeneral
Displacement149.3 cc
Bore x Stroke57.3 mm x 57.9 mm
Compression Ratio10.6:1
Fuel SystemPGM-FI (Programmed Fuel Injection)
Ignition SystemFull Transistorized Ignition
Starting SystemElectric
Front SuspensionTelescopic Fork
Front BrakeHydraulic Disc
Rear BrakeMechanical Drum
Front Tire110/80-14
Rear Tire130/70-13
Length1, 950 mm
Width763 mm
Height1, 153 mm
Seat Height795 mm
Wheelbase1, 324 mm
Ground Clearance165 mm
Curb Weight133 kg
Engine TypeLiquid-cooled, 4-stroke, SOHC
TransmissionAutomatic, V-Matic
Rear SuspensionTwin Shock
Fuel Tank Capacity8.0 L
