Battery Cover
#
Removal
1.
Open the seat. 2 P. 62
2.
Press the tabs and remove the battery
cover.
#
Installation
Install the parts in the reverse order of
removal.
20191017191217_32K0WC000_eng_BOOK Page 86 Thursday, October 17 2019 19:17:25 JST
Removing & Installing Body Components u Battery Cover
Maintenance
83
Tabs
Battery cover

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Honda ADV150 2019 and is the answer not in the manual?

Honda ADV150 2019 Specifications

General IconGeneral
Displacement149.3 cc
Bore x Stroke57.3 mm x 57.9 mm
Compression Ratio10.6:1
Fuel SystemPGM-FI (Programmed Fuel Injection)
Ignition SystemFull Transistorized Ignition
Starting SystemElectric
Front SuspensionTelescopic Fork
Front BrakeHydraulic Disc
Rear BrakeMechanical Drum
Front Tire110/80-14
Rear Tire130/70-13
Length1, 950 mm
Width763 mm
Height1, 153 mm
Seat Height795 mm
Wheelbase1, 324 mm
Ground Clearance165 mm
Curb Weight133 kg
Engine TypeLiquid-cooled, 4-stroke, SOHC
TransmissionAutomatic, V-Matic
Rear SuspensionTwin Shock
Fuel Tank Capacity8.0 L
