Specifications
■ Main Components
Overall length 1,950 mm (76.8 in)
Overall width 763 mm (30.0 in)
Overall height 1,153 mm (45.4 in)
Wheelbase 1,324 mm (52.1 in)
Minimum ground
clearance
165 mm (6.5 in)
Caster angle 26º 30’
Trail 85 mm (3.3 in)
Curb weight 133 kg (293 lb)
Maximum weight
capacity
*1
140 kg (309 lb)
Maximum luggage
weight
*2
Centre
compartment
10 kg (22 lb)
Front box 1.0 kg (2.2 lb)
Passenger capacity Rider and 1 passenger
Minimum turning radius 1.90 m (6.2 ft)
*1 : Including rider, passenger, all luggage, and accessories.
*2 : Includes the weight of the luggage and added accessories.
Displacement 149.32 cm
3
(9.109 cu-in)
Bore x stroke
57.300 x 57.907 mm (2.2559 x 2.2798
in)
Compression ratio 10.6:1
Fuel
Unleaded petrol
Recommended: 91 RON or higher
Fuel containing alcohol ETHANOL up to 10 % by volume
Tank capacity 8.0 L (2.11 US gal, 1.76 Imp gal)
Batte
ry
YTZ6V or FTZ6V
12 V-5.0 Ah (10 HR)
Primary reduction V-Matic (2.52:1 to 0.81:1)
Final reduction 9.854
20191017191217_32K0WC000_eng_BOOK Page 144 Thursday, October 17 2019 19:17:25 JST
Specifications
141

Honda ADV150 2019 Specifications

General

Displacement	149.3 cc
Bore x Stroke	57.3 mm x 57.9 mm
Compression Ratio	10.6:1
Fuel System	PGM-FI (Programmed Fuel Injection)
Ignition System	Full Transistorized Ignition
Starting System	Electric
Front Suspension	Telescopic Fork
Front Brake	Hydraulic Disc
Rear Brake	Mechanical Drum
Front Tire	110/80-14
Rear Tire	130/70-13
Length	1, 950 mm
Width	763 mm
Height	1, 153 mm
Seat Height	795 mm
Wheelbase	1, 324 mm
Ground Clearance	165 mm
Curb Weight	133 kg
Engine Type	Liquid-cooled, 4-stroke, SOHC
Transmission	Automatic, V-Matic
Rear Suspension	Twin Shock
Fuel Tank Capacity	8.0 L
