Honda EM5000SXK3AN User Manual

OPTIONAL PARTS
111
HANGER KIT
1. Position the hanger at the generator’s balance point as shown below.
2. Fit the end tabs of the hanger through the bracket slots, and bolt the brackets
to the hanger and tighten securely.
Torque: 19.5 lbf·ft (26.5 N·m, 2.7 kgf·m)
8×16 mm FLANGE BOLT (4)
HANGER
HANGER BRACKET (2)
11 in (280 mm)
HANGER
GENERATOR
SIDE

Honda EM5000SXK3AN Specifications

General

Brand	Honda
Model	EM5000SXK3AN
Category	Portable Generator
Language	English
