Honda EU70is User Manual

34
OPERATION
2.Make sure the Eco-Throttle
switch is in the OFF position, or
more time will be required for
warm-up.

If you wish to use the 
Eco-Throttle system, turn the
Eco-Throttle switch to the ON
position after the engine has
warmed up for 2 or 3 minutes.
3.Turn the MAIN switch to the ON
position.
4.Press and release the ENGINE
START button.

The ENGINE START button
functions for 5 seconds. As
soon as the engine starts, the
starter will stop automatically.
If the engine fails to start, wait
at least 10 seconds before
operating the starter again.
Do not leave the MAIN switch in the ON position when the 
generator is not operating or the battery will be drained. Turn the
MAIN switch to the OFF position when not in use.
ONOFF
ECO-THROTTLE SWITCH
MAIN SWITCH
ENGINE START BUTTON
ON
OFF
∙∙∙OFF
∙∙∙ON
36Z376000.book 34 ページ ２０１４年９月１９日 金曜日 午後６時２６分

Honda EU70is Specifications

General

Model	EU70is
Type	Inverter
Maximum AC Output	7000 VA
Rated AC Output	5500 VA
Engine	GX390
Engine Displacement	389 cc
Fuel Type	Gasoline
Run Time per Tankful	6.5 hours at rated load
Starter System	Electric
DC Output	12V, 8.3A
Run Time at 1/4 Load	18 hours
Noise Level	52 dB(A) at 1/4 load
Rated Voltage	220-240V
