Honda EU70is User Manual

35
OPERATION
• Use the recoil starter when
the battery voltage is too low
to turn the starter motor.
a. Turn the MAIN switch to
the ON position.
b.Open the right maintenance
cover by turning its latch
counterclockwise.
c. Pull the starter grip lightly
until you feel resistance;
then pull briskly in the
direction of the arrow as
shown.
• Do not exceed 20
degrees from horizontal
when pulling the starter
grip.
• Do not allow the starter
grip to snap back against
the engine. Return it
gently to prevent
damage to the starter.
• Do not let the starter
rope rub against the
generator body, or the
rope will wear out
prematurely.
d.Close the right 
maintenance cover by 
turning its latch clockwise.
5.If you wish to use the 
Eco-Throttle system, turn the
Eco-Throttle switch to the ON
position after the engine has
warmed up for 2 or 3 minutes.
MAIN SWITCH
ON
20°
STARTER GRIP
ECO-THROTTLE SWITCH
OFF ON
OFF
∙∙∙OFF
∙∙∙ON
36Z376000.book 35 ページ ２０１４年９月１９日 金曜日 午後６時２６分

Honda EU70is Specifications

General

Model	EU70is
Type	Inverter
Maximum AC Output	7000 VA
Rated AC Output	5500 VA
Engine	GX390
Engine Displacement	389 cc
Fuel Type	Gasoline
Run Time per Tankful	6.5 hours at rated load
Starter System	Electric
DC Output	12V, 8.3A
Run Time at 1/4 Load	18 hours
Noise Level	52 dB(A) at 1/4 load
Rated Voltage	220-240V
