Honda Forza NSS300 2013 User Manual

Serial Numbers
107
Information
Serial Numbers
The frame and engine serial numbers uniquely
identify your scooter and are required in order
to register your scooter. They may also be
required when ordering replacement parts.
The frame number is stamped on the rear of the
frame body inside the luggage box.
The engine number is stamped on the left side
of the crankcase.
You should record these numbers and keep
them in a safe place.
❙
Frame number
1. Open the seat. 2 P. 38
2. Remove the document compartment.
3. Remove the clips. 2 P. 61
4. Remove the tool box.
5. Install the parts in the reverse order of
removal.
Frame number
Document
compartment
Clips
Tool box
Engine number

Honda Forza NSS300 2013 Specifications

General

Displacement	279 cc
Compression Ratio	10.5:1
Fuel System	PGM-FI electronic fuel injection
Ignition	Computer-controlled digital transistorized with electronic advance
Transmission	Automatic V-Matic belt drive
Front Tire	120/70-14
Rear Tire	140/70-13
ABS	Optional
Engine Type	Liquid-cooled, 4-stroke, single-cylinder
Front Suspension	33mm telescopic fork
Rear Suspension	Twin shock
Front Brake	Single 256 mm disc
Rear Brake	Single 240mm disc
Wheelbase	60.9 inches
Seat Height	28.2 inches
Width	29.7 inches
Curb Weight	192 kg (423 lbs)
