Honda Forza NSS300 2013 User Manual

73
Maintenance
Brakes
Checking Brake Fluid
1. Place your scooter in an upright position
on a firm, level surface.
2. Check that the brake fluid reservoir is
horizontal and that the fluid level is above
the lower level mark.
If the brake fluid level in either reservoir is
below the LOWER level mark or the brake
lever freeplay becomes excessive, inspect the
brake pads for wear. If the brake pads are
not worn, you most likely have a leak. Have
your scooter inspected by your dealer.
Front
Rear
Front brake fluid reservoir
LOWER level
mark
Rear brake fluid reservoir
LOWER level
mark

Honda Forza NSS300 2013 Specifications

General

Displacement	279 cc
Compression Ratio	10.5:1
Fuel System	PGM-FI electronic fuel injection
Ignition	Computer-controlled digital transistorized with electronic advance
Transmission	Automatic V-Matic belt drive
Front Tire	120/70-14
Rear Tire	140/70-13
ABS	Optional
Engine Type	Liquid-cooled, 4-stroke, single-cylinder
Front Suspension	33mm telescopic fork
Rear Suspension	Twin shock
Front Brake	Single 256 mm disc
Rear Brake	Single 240mm disc
Wheelbase	60.9 inches
Seat Height	28.2 inches
Width	29.7 inches
Curb Weight	192 kg (423 lbs)
