Honda Forza NSS300 2013 User Manual

30
Switches (Continued)
Operation Guide
Steering Lock
Lock the steering when parking to help
prevent theft.
A U-shaped wheel lock or similar device is
also recommended.
❙
Locking
!a Turn the handlebar all the way to the left.
!b Push the key down, and turn the ignition
switch to the LOCK position.
u Jiggle the handlebar if the lock is difficult
to engage.
!c Remove the key.
❙
Unlocking
Insert the key, and turn the ignition switch to
the OFF position.
Push
Ignition key
Turn
Except U, KO type
U, KO type
Push
Turn
!a
!b
!b

Honda Forza NSS300 2013 Specifications

General

Displacement	279 cc
Compression Ratio	10.5:1
Fuel System	PGM-FI electronic fuel injection
Ignition	Computer-controlled digital transistorized with electronic advance
Transmission	Automatic V-Matic belt drive
Front Tire	120/70-14
Rear Tire	140/70-13
ABS	Optional
Engine Type	Liquid-cooled, 4-stroke, single-cylinder
Front Suspension	33mm telescopic fork
Rear Suspension	Twin shock
Front Brake	Single 256 mm disc
Rear Brake	Single 240mm disc
Wheelbase	60.9 inches
Seat Height	28.2 inches
Width	29.7 inches
Curb Weight	192 kg (423 lbs)
