Honda Forza NSS300 2013 User Manual

18
Operation Guide
Operation Guide
Parts Location
Engine oil drain bolt (P68)
Front brake fluid reservoir
(P73)
Throttle grip (P76)
Engine oil fill cap/dipstick
(P67)
Document bag (P40)
Luggage box (P40)
Battery (P62)
Fuse box 1, Main fuse 1
(P91)
Front brake lever
Tool kit (P59)
Coolant reserve tank (P71)
Right fairing pocket (P41)
Fuse box 2, 3 (P92)
Main fuse 2 (P94)

Honda Forza NSS300 2013 Specifications

General

Displacement	279 cc
Compression Ratio	10.5:1
Fuel System	PGM-FI electronic fuel injection
Ignition	Computer-controlled digital transistorized with electronic advance
Transmission	Automatic V-Matic belt drive
Front Tire	120/70-14
Rear Tire	140/70-13
ABS	Optional
Engine Type	Liquid-cooled, 4-stroke, single-cylinder
Front Suspension	33mm telescopic fork
Rear Suspension	Twin shock
Front Brake	Single 256 mm disc
Rear Brake	Single 240mm disc
Wheelbase	60.9 inches
Seat Height	28.2 inches
Width	29.7 inches
Curb Weight	192 kg (423 lbs)
