Honda Forza NSS300 2013 User Manual

Removing & Installing Body Components u Battery
62
Maintenance
Battery
❙
Removal
Make sure the ignition switch is off.
1. Remove the battery cover. 2 P. 60
2. Disconnect the negative - terminal from
the battery.
3. Disconnect the positive + terminal from
the battery.
4. Remove the battery by lifting on the
battery strap with one hand while
supporting the battery with the other,
taking care not to drop the battery
terminal nuts.
❙
Installation
Install the parts in the reverse order of
removal. Always connect the positive +
terminal first. Make sure that bolts and nuts
are tight.
Readjust the clock after the battery is
reconnected since the clock goes wrong
once the battery is disconnected.
For proper handling of the battery, see
“Maintenance Fundamentals.”
2 P. 51
Battery Goes Dead
2 P. 85
Negative
terminal
Positive
terminal
Battery
Battery
strap

Honda Forza NSS300 2013 Specifications

General

Displacement	279 cc
Compression Ratio	10.5:1
Fuel System	PGM-FI electronic fuel injection
Ignition	Computer-controlled digital transistorized with electronic advance
Transmission	Automatic V-Matic belt drive
Front Tire	120/70-14
Rear Tire	140/70-13
ABS	Optional
Engine Type	Liquid-cooled, 4-stroke, single-cylinder
Front Suspension	33mm telescopic fork
Rear Suspension	Twin shock
Front Brake	Single 256 mm disc
Rear Brake	Single 240mm disc
Wheelbase	60.9 inches
Seat Height	28.2 inches
Width	29.7 inches
Curb Weight	192 kg (423 lbs)
