Page #113 background imageLoading...
Page #113 background image
Specifications
110
Specifications
■ Bulbs
■ Fuses
■ Torque Specifications
Headlights 12V-35/35W × 2
Brake lights 12V-16W × 2
Tail lights 12V-5W × 2
Front turn signal/
Position lights
12V-21/5W × 2
Rear turn signal lights 12V-21W × 2
License plate light 12V-5W
Main fuse 1 30A
Main fuse 2 30A
Other fuses
NSS300
15A, 10A, 5A
NSS300A
30A, 15A, 10A, 5A
Engine oil drain bolt 25 N·m (2.5 kgf·m, 18 lbf·ft)
Oil filter 26 N·m (2.7 kgf·m, 19 lbf·ft)

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Honda Forza NSS300 2013 and is the answer not in the manual?

Honda Forza NSS300 2013 Specifications

General IconGeneral
Displacement279 cc
Compression Ratio10.5:1
Fuel SystemPGM-FI electronic fuel injection
IgnitionComputer-controlled digital transistorized with electronic advance
TransmissionAutomatic V-Matic belt drive
Front Tire120/70-14
Rear Tire140/70-13
ABSOptional
Engine TypeLiquid-cooled, 4-stroke, single-cylinder
Front Suspension33mm telescopic fork
Rear SuspensionTwin shock
Front BrakeSingle 256 mm disc
Rear BrakeSingle 240mm disc
Wheelbase60.9 inches
Seat Height28.2 inches
Width29.7 inches
Curb Weight192 kg (423 lbs)
