Honda Forza NSS300 2013 User Manual

77
Maintenance
Other Adjustments
Adjusting the Rear Suspension
❙
Spring Preload
You can adjust the spring preload by the
adjuster to suit the load or the road surface.
Use the pin spanner to turn the adjuster.
Position 1 and 2 are is for a decrease spring
preload (soft), or turn the position 4 and 5 to
increase spring preload (hard). The standard
position is 3.
Adjusting the Headlight Aim
You can adjust vertical aim of the headlights
for proper alignment. Turn the pinion using a
Phillips screwdriver provided in the tool kit
(
2 P. 59) in or out as necessary.
Obey local laws and regulations.
NOTICE
Do not turn the adjuster beyond its limits.
Adjuster
Pin spanner
12345
Lower
Raise
Pinion

Honda Forza NSS300 2013 Specifications

General

Displacement	279 cc
Compression Ratio	10.5:1
Fuel System	PGM-FI electronic fuel injection
Ignition	Computer-controlled digital transistorized with electronic advance
Transmission	Automatic V-Matic belt drive
Front Tire	120/70-14
Rear Tire	140/70-13
ABS	Optional
Engine Type	Liquid-cooled, 4-stroke, single-cylinder
Front Suspension	33mm telescopic fork
Rear Suspension	Twin shock
Front Brake	Single 256 mm disc
Rear Brake	Single 240mm disc
Wheelbase	60.9 inches
Seat Height	28.2 inches
Width	29.7 inches
Curb Weight	192 kg (423 lbs)
