Honda Forza NSS300 2013 User Manual

Electrical Trouble u Blown Fuse
91
continued
Troubleshooting
Blown Fuse
Before handling fuses, see “Inspecting and
Replacing Fuses.” 2 P. 52
❙
Fuse Box 1 Fuses & Main Fuse 1
(NSS300A)
(NSS300)
1. Remove the battery cover. 2 P. 60
2. Open the fuse box cover.
3. Pull the main fuse 1 and other fuses out
with the fuse puller in the tool kit one by
one and check for a blown fuse. Always
replace a blown fuse with a spare of the
same rating.
Spare
fuses
Main fuse 1
Fuse box cover
Fuse box 1
Spare
fuses
Main fuse 1
Fuse box cover
Fuse box 1

Honda Forza NSS300 2013 Specifications

General

Displacement	279 cc
Compression Ratio	10.5:1
Fuel System	PGM-FI electronic fuel injection
Ignition	Computer-controlled digital transistorized with electronic advance
Transmission	Automatic V-Matic belt drive
Front Tire	120/70-14
Rear Tire	140/70-13
ABS	Optional
Engine Type	Liquid-cooled, 4-stroke, single-cylinder
Front Suspension	33mm telescopic fork
Rear Suspension	Twin shock
Front Brake	Single 256 mm disc
Rear Brake	Single 240mm disc
Wheelbase	60.9 inches
Seat Height	28.2 inches
Width	29.7 inches
Curb Weight	192 kg (423 lbs)
