or 31,5° Baumé) until the indicated level is reached, distrib-
uting it evenly among the six elements.
Close the six caps
(5) which are includ-
ed and begin charg-
ing the battery.
Remount the bat-
tery on the ma-
chine.
The elastic strap (2)
shoud be placed
behind the filling
caps (5) of the battery.
Connect the red cable (6) to first the positive terminal (+)
then the black cable (7) to the negative terminal (–) using
the supplied screws as indicated.
Grease the terminals with silicon grease, making sure that
the protective cap of the red cable (6) is positioned correct-
ly.
After having activated the battery, continue charging it com-
pletely. Contact your Dealer who has all of the proper equipment available. The
battery charger supplied is NOT able to carry out the first charging of the bat-
tery after it has been activated..
To prevent the safety device in the electronics card from cut-
ting in, never start the engine until the battery is fully charged!
Battery acid is corrosive and a pollutant. When handling,
use protective gloves and dispose of properly following current regula-
tions.
3.6 GRASS-CATCHER SUPPORT
ASSEMBLY
Fit the two brackets (1) on the rear plate
(2), using for each bracket three screws
(3) which are supplied, as shown, without
fully tightening the nuts (4).
The supports (1) must be mounted so that
!
WARNING!
IMPORTANT
IMPORTANT
EN 11UNPACKING AND ASSEMBLY
