EN 49MAINTENANCE
– turn both the rear screws (5) until the rear
of the deck begins to rise both at the right
and the left, and then tighten the relative
locknuts (6).
If you are unable to adjust the cutting deck properly, contact your Dealer.
6.3.3 A
DJUSTING BLADE ENGAGEMENT AND BLADE BRAKE
When the lever to disengage the blades is operated, this also brings the blade
brake into operation for stopping the blades within few seconds.
A stretched cable and changes in the length of the belt can impair the blades’
engagement or rotation.
In this case, you have to work on the adjuster according to the different methods
provided for each model.
In any event, if the engagement is unable to normally drive the belt or the blades
do not stop within a few seconds after adjustment, immediately contact your Deal-
er.
Turn the adjusting nut (1) until the correct
spring length (2) is achieved (measured
with the blade engaged).
Turn the adjusting nut (1) until the correct
spring length (2) is achieved (measured
with the blades engaged).
HF2415SBE
➤
HF2315SBE
➤
