EN 23HOW TO USE
To start the engine, in all cases it is necessary that:
– the transmission is in “neutral”;
– the blades are not engaged;
– the operator is seated or the parking brake is engaged.
The engine stops when:
– the operator leaves his seat when the blades are engaged;
– the operator leaves his seat when the transmission is not in “neutral”;
– the operator leaves his seat with the transmission in “neutral” but without
engaging the parking brake;
– the grass-catcher is lifted or the stone-guard is removed when the blades are
engaged;
– the reverse gear is engaged with the blades engaged. This can be avoided by
keeping the push-button 4.7 pressed.
The table below shows various operating conditions, highlighting
why the safety
device shuts down the engine.
OPERATOR GR.-CATCHER BLADES TRANSMISSION BRAKE ENGINE
A) PILOT LAMPS ON (Key in «ON» position)
Sitting YES Disengaged «N» Engaged Stopped
Sitting NO Disengaged «N» Disengaged Stopped
B) WHEN STARTING (Key in «START» position)
Sitting –/– Disengaged 1...5 - F / R Engaged Does NOT start
Sitting –/– Engaged «N» Engaged Does NOT start
Absent –/– Disengaged «N» Disengag
ed
Does NOT start
C) WHEN MOVING (Key in «ON» position)
Sitting YES Disengaged 1...5 - F / R Engaged Stops
Absent YES Disengaged «N» Disengaged Stops
D) WHEN CUTTING GRASS (Key in «ON» position)
Sitting NO Engaged –/– Disengaged Stops
Sitting YES Enga
ged R Disengaged Stops*
Absent YES Disengaged «N» Disengaged Stops
Absent YES Engaged –/– Engaged Stops
* This may be avoided by keeping the push-button 4.7 pressed.
