12 - 2
1902 Scanner Product Specifications
*Storage outside of this temperature range could be detrimental to battery life.
Parameter Specification
Dimensions (Typical):
Height
6.3 inches (16 cm)
Length
4.1 inches (10.41cm)
Width
2.8 inches (7.11cm)
Weight
7.5 ounces (212.62g)
Illumination:
Scan and Aiming LEDs
LED output power
617nm +
18nm
.339mW
Image Size 838 x 640 pixels
Skew Angle +
65°
Pitch Angle +
45°
Motion Tolerance:
Streaming Presentation Trigger up to 240 inches per second for 13 mil UPC
Symbol Contrast Grade 1.0 (20% or greater)
Battery:
Lithium Ion
1800 mAHr minimum
Number of Scans Up to 50,000 per charge
Expected Hours of Operation 14
Expected Charge Time 4.5 hours
Radio:
Frequency
2.4 to 2.5 GHz (ISM Band) Frequency Hopping
Bluetooth v.2.1
Range
33 ft. (10 m) typical
Data Rate
Up to 1 MBps
Temperature Ranges:
Operating
32° F to +122° F (0° C to 50° C)
Storage*
-40°F to +158°F (-40°C to 70°C)
Humidity Up to 95% non-condensing
Mechanical Drop
Operational after 50 drops from 6 feet
(1.8 m) to concrete
Vibration Withstands 5G peak from 22 to 300 Hz
ESD Sensitivity
Up to 15kV direct air
Up to 8 kV indirect coupling plane
Sealant Rating IP41
