List of Field-Replaceable Components
8500C/8500C+ System Maintenance Manual 5-75
2-3 − * * Printer Paper 62712 TP411-451-25C 610-199
5-17 56 * * Label, Serial 99866 − 11287
Table 5-16. 8520C Signal Selector
FIG
NO.
REF
NO.
COMPONET
1 2 3 4 5 6 7 (Assy. Level) CAGE MFG. P/N C-H P/N
5-20 * 8520C Signal Selector
99866 −
11130A
5-20 A1 * * Controller/Bit Board
99866 −
11082A
* * * IC, Programmed U12, V.
99866 −
9866-7
* * * IC, Programmed U15, V.
99866 −
9964B
5-20 A2 * * Power Supply Board
99866 −
10835-1
* * * Fuse, 2.5A 250V FAST 5x 03614 GDB2.5A 301-20258
5-20 A3 * * Quad Peak Detector Board
99866 −
12508-1
5-20 2 * * Filter Assy., Dual
99866 −
10857A
5-21 * * Harness Assy., PWR/SIG
99866 −
11127
5-21 * * Harness Assy., VEL/MAG
99866 −
9689
5-20 5 * * Screw, 4-40 X 3-8 Pan. Php.
Blk. Qty. 94
96906 MS51957-15B 651-4523
5-20 6 * * Nut, 4-40 Nylon Lock
Standard Qty. 12
39428 90631A005 652-45NS
5-20 7 * * Washer, #4 Std. Intl. Lck. 260”,
Qty. 28
96906 MS35333-36 654-4SIA
5-20 8 * * Standoff, 4-40 X 1 3/8 Hex 1/4
Qty. 6
83330 130-21 ST 4-
40-x
660-14B4
5-20 9 * * Standoff, #4 Clear Rnd. 1/4
O.D. Qty. 2
83330 8481 660-2424
5-20 10 * * Bumper, Rubber Qty. 4 76385 ZB-1160-MI 610-094
5-20 11 * * Chassis
99866 −
10831A
5-20 12 * * Cover
99866 −
10830
Table 5-15. 8500C/C+ Balancer/Analyzer
FIG
NO.
REF
NO.
COMPONENT
1 2 3 4 6 7 8 (Assy. Level) CAGE MFG. P/N C-H P/N
(Continued)
