8500C/8500C+ System Maintenance Manual D-19
Table D-5. Bill Of Material For 8520CS
REF.
NO.
COMPONENT QTY.
CAGE
CODE
MFG.
P/N
C-H P/N
*8520CS SIGNAL SELECTOR 99866 14880
A1 **PCB ASSY. SIGNAL CONDITIONER 1 99866 801-14871
A2 PCB ASSY. POWER SUPPLY 1 99866 801-10835A
A3 ** PCB ASSY. 8520CS CONTROLLER 1 99866 801-14918
1 ** LABEL SERIAL 1 99866 753-11287
2 ** FILTER DUAL 8520C TE 99866 820-10857A
3 ** HARNESS ASSY. PWR/SIG 99866 802-11127
4 ** HARNESS ASSY. 2 99866 802-14876
5 ** SCREW 4-40 X 3/8 PHP 94 99866 651-4523
6 ** NUT 4-40 NYLOCKSTD. 4 99866 652-45NS
7 ** WASHERS #4 STD INT LOCK 28 99866 654-4SIA
8 ** STANDOFF 4-40 X 1-3/4 6 99866 660-14B4
9 ** SPACER #4 I.D. .25 O.D. 2 99866 660-2424
10 ** BUMPER RUBBER 4 99866 610-094
11 ** CHASSIS 8520CS EMI 1 99866 751-14868
12 ** COVER 8520CS EMI 1 99866 562-14867
13 ** LED GREEN PANEL MOUNT 2 99866 251-L502
14 ** WASHER HOLDER #4 6 99866 654-4SBA
15 ** SPACER 1/2” X 1/4 O.D 6 99866 660-D444
16 ** TY-WRAP 15 99866 660-T01
18 ** SCREW 10-32 X 5/16 PHP 4 99866 651-9422
19 ** SCREW 4-40 X 7/8 PHP 6 99866 651-4527
20 ** WIRE GREEN 18AWG STRANDED 1 99866 702-185
21 ** #4 SOLDER LUG BENT 1 99866 408-B442C
25 ** NUT RING #14 W/STUD 4 99866 405-14Z5R
26 ** NUT RING #10 W/STUD 8 99866 405-10Z5R
27 ** NUT RIGN *8 W/STUD 8 99866 405-08Z5R
28 ** LABLE “CE” MARK 1X1X 1 99866 752-13594
29 ** LED RED PANEL MOUNT 2 99866 251-L503
To Next Page
