Honeywell Chadwick-Helmuth 8500C User Manual

A-30 Chadwick-Helmuth A Business Unit of Honeywell International, Inc.
Appendix A - 8520C-36 Signal Selector
A.5 8520C-36 List of Field-Replaceable
Components
Table A-1. 8520C-36 Signal Selector
FIG
NO.
REF
NO.
COMPONENT
1 2 3 4 5 6 7 (Assy. Level) CAGE MFG. P/N C-H P/N
* 8520C-36 Signal Selector
99866
11518A
A-10 A1 * * PCB Assy, Connector, Qty. 4
99866
11671
A-10 A3 * * Controller/Bit Board
99866
11676
* * * IC, Programmed V. 1.03 (or
higher)
99866
11843-1
A-10 A2 * * Power Supply Board
99866
10835A
A-10 * * * Fuse, 2.5A 250V FAST 5x 03614 GDB2.5A 301-20258
A-10 A4 * * Mux, PCB Assy
99866
11678
A-10 2 * * Filter, Assy., Dual
99866
10857A
A-10 3 * * Screw, 4-40 X 3/8 Php. Blk.,
Qty. 78
96906 MZ35216-14 651-4523
A-10 4 * * Washer Shoulder, #4, Qty. 13 04713 B51547F019 654-4SBA
A-10 5 * * Screw, 4-40 X 3/4 Pan. Php.
Blk. Qty. 5
96906 MS35216-18B 651-4526
A-10 6 * * Nut, 4-40 Nylon Lock
Standard Qty. 6
39428 90631A005 652-45NS
A-10 7 * * Washer, #4 Std. Intl. Lck. 260”
Qty. 22
83330 1127C 654-4SIA
A-10 8 * * Standoff, 4-40 X 1.25 Hex
Metal 1/4 Qty. 6
83330 8408 660-14A4
A-10 9 * * Standoff, #4 Clear Rnd. 1/4
O.D., .25 Long Qty. 8
83330 8481 660-2424
A-10 10 * * Bumper, Rubber Qty. 4 76385 ZB-1160-MI 610-094
A-10 11 * * Chassis, 8520C-36
99866
11679A
A-10 12 * * Cover
99866
10830
