XLS-REL Technical Reference Manual 1.5
Installing the XLS-REL
Compatible panels and devices
Panels
The XLS-REL is compatible with XLS100 and XLS1000 fire
alarm control panels. You may install the XLS-REL in any of the
following enclosures:
•XLS-WB(X) series
• RACCR series
• 3-RCC series
• 3-CAB series
•MFC-A
Note: Maintain a 1-inch (25.4 mm) minimum clearance all
around the XLS-REL. The clearance space must also comply
with the National Electrical Code.
Power supplies
The XLS-REL is compatible with the following power supplies:
• 2-PPS(-220)
• 2-PPS/6A(-220)
• SIGA-APS(-220)
• 3-BPS/M(-220)
• 3-PPS/M(-220)
• XLS-BPS6(-220)*
• XLS-BPS10(-220)*
*Not compatible with FMRC sprinkler applications that require
90 hours of standby.
Solenoid polarizing relays
Use the RELA-EOL with the XLS-REL. For more information,
see the RELA-EOL installation sheet.
Abort stations
The XLS-REL is only compatible with normally-open,
momentary-action abort stations. Abort stations must be listed
with the appropriate agencies in your area. See Listing agencies.
Service disconnect stations
The XLS-REL is only compatible with listed service disconnect
stations that are normally-closed (minimum 2.0 Amps). Service
disconnect stations must be listed with the appropriate agencies in
your area. See Listing agencies.
