Honeywell XLS-REL User Manual

Operational description
3.4 XLS-REL Technical Reference Manual
Developing a fire suppression plan
The Releasing Module consists of two releasing circuits, which
provide fire suppression in two separate areas. The computer
room illustrated in Figure 3-3 is a typical application for the
Releasing Module.
Figure 3-3: Typical computer room application
Signature loop controller
Releasing Module
SD
RELEASE015.CDR
Fire alarm control panel
Legend
Signature Series smoke detectors
Horn circuit
Strobe circuit
Service disconnect station
Manual abort station
Manual release station
SD
Raised floor
Slab
2 1
Extinguishing
agent
storage
cylinder
Release circuit 1
Release circuit 2
Wall-mounted agent release nozzle
Ceiling-mounted agent release nozzle
RELA-EOL
RELA-EOL
AMR
A
MR
SD
