XLS-REL Technical Reference Manual 2.1
Chapter 2
Programming the XLS-REL
Summary
The XLS-REL works with XLS100 and XLS1000 systems. The
XLS100-SDU and the XLS1000-SDU (Revision 1.5) recognize
the XLS-REL as three SIGA-UM modules that occupy six
addresses. The XLS1000-SDU (Revision 2.0) does not require
you to select SIGA-UMs because it recognizes the XLS-REL.
In all systems, the programming procedures for the XLS-REL are
almost identical. The greatest differences exist in the required
rules and the configuration of AND groups. The XLS-REL
programming steps require strict adherence. Follow each
instruction carefully.
Content
Programming the XLS-REL in the XLS100-SDU • 2.2
Adding the XLS-REL to the database • 2.2
Labeling the XLS-REL components • 2.4
Programming an AND group • 2.4
Reconciling the Signature map • 2.4
Writing rules for the XLS-REL • 2.4
Programming the XLS-REL in the XLS1000-SDU (Revision 1.5) •
2.6
Adding the XLS-REL to the database • 2.6
Labeling the XLS-REL components • 2.8
Programming an AND group • 2.8
Reconciling the Signature map • 2.9
Writing rules for the XLS-REL • 2.9
Programming the XLS-REL in the XLS1000-SDU (Revision 2.0) •
2.10
Adding the XLS-REL to the database • 2.10
Labeling the XLS-REL components • 2.12
Programming an AND group • 2.12
Reconciling the Signature map • 2.13
Writing rules for the XLS-REL • 2.13
System testing • 2.14
Testing XLS100 systems • 2.14
Testing XLS1000 systems • 2.14
