Programming the XLS-REL
2.4 XLS-REL Technical Reference Manual
Labeling the XLS-REL components
In the Object Configuration, assign the labels and messages listed
in Table 2-3 to the SIGA-UM.
*The addresses in Table 2-3 demonstrate the importance of
ensuring that the XLS-REL occupies six consecutive addresses.
The actual addresses in your system may differ.
Programming an AND group
AND groups function as cross zones. For more information about
programming AND groups, see the XLS100 System Programming
Manual and the XLS100-SDU Help.
Note: Every device contained in each (XLS-REL) AND group
must include a rule with an output statement like the one in
[ALARM1]. See Figure 2-1 for the details.
Reconciling the Signature map
Caution! Do not use Accept Actual in the Signature Series
mapping tool. Accepted devices may appear as two devices in the
SDC database and corrupt it. Use the Break Chain and Commit
Expected functions to reconcile the Signature map.
Writing rules for the XLS-REL
To write the rules:
1 In the Rules Editor, write the mandatory rules in Figure 2-1
and the optional rules in Figure 2-2.
2 Compile the rules and run the required conversions.
3 Download and upload the new information.
Table 2-3: XLS-REL labels
Device Type Typical address Label Message Model
Monitor 0207* Abort Abort SIGA-UM
Pull 0208* Manual Manual SIGA-UM
DoorControl 0209* Release_1 Release_1 SIGA-UM
None 0210* Release_2 Release_2 SIGA-UM
DoorControl 0211* Prerelease_1 Prerelease_1 SIGA-UM
None 0212* Prerelease_2 Prerelease_2 SIGA-UM
