HP 100B SFF User Manual

41
System Recovery at System Startup
CAUTION: System Recovery deletes all data and programs you created or installed. Back up any
important data to a removable disc.
If Windows is not responding, but the computer is working, follow these steps to perform a System
Recovery.
1. Turn off the computer. If necessary, press and hold the On button until the computer turns off.
2. Disconnect all peripheral devices from the computer, except the monitor, keyboard, and mouse.
3. Press the On button to turn on the computer.
4. As soon as you see the initial company logo screen appear, repeatedly press the F11 key on your
keyboard until the Windows is Loading Files… message appears on the screen.
5. Under I need help immediately, click System Recovery.
6. If you are prompted to back up your files, and you have not done so, select Back up your files
first (recommended), and then click Next. Otherwise, select Recover without backing
up your files, and then click Next.
7. System Recovery begins. After System Recovery is complete, click Finish to restart the computer.
8. Complete the registration process, and wait until you see the desktop.
9. Turn off the computer, reconnect all peripheral devices, and turn the computer back on.
System Recovery from Recovery Discs
CAUTION: System Recovery deletes all data and programs you created or installed. Back up any
important data to a removable disc.
To create recovery discs, see Recovery Discs on page 42.
To perform a System Recovery using recovery discs:
1. If the computer is working, create a backup DVD containing all the data files you want to save,
and then remove the backup disc from the drive tray.
2. Insert recovery disc #1 into the DVD drive tray, and close the tray.
3. If the computer works, click the Start button, click the Arrow button next to Shut Down, and then
click Shut Down. Or, if the computer is not responding, press and hold the On button for
approximately 5 seconds, or until the computer turns off.
4. Disconnect all peripheral devices from the computer except the monitor, keyboard, and mouse.
5. Press the On button to turn on the computer. If you are prompted to choose between running
System Recovery from disc or from hard drive, select Run program from disc, and then click
Next.
6. Under I need help immediately, click Factory Reset.
7. If you are prompted to back up your files, and you have not done so, select Back up your files
first (recommended), and then click Next. Otherwise, select Recover without backing
up your files, and then click Next.
8. If you are prompted to insert the next recovery disc, do so.
9. When the Recovery Manager is finished, remove all recovery discs from the system.
10. Click Finish to restart the computer.

HP 100B SFF Specifications

Operating Environment

operating temperature range	10° to 35°C
nonoperating temperature range	-30° to 60°C
operating relative humidity	10-90%
nonoperating relative humidity	5-95%
operating maximum altitude	3048 m
nonoperating maximum altitude	9144 m

Power

operating voltage range	90-137Vac
rated voltage range	100-127Vac
rated line frequency	50-60Hz
power output	65 W
rated input current	1.6A @ 90 VAC

Weight and Dimensions

height	27 cm
width	10 cm
depth	34.79 cm
weight	4.8 kg
