HP 100B SFF User Manual

60
Do not know how to remove a media card correctly.
Cause Solution
The computer’s software is used to safely eject the card.
After installing the media card reader and booting to Windows, the reader and the inserted cards are
not recognized by the computer.
Cause Solution
The operating system needs time to recognize the device if the
reader was just installed into the computer and you are
turning the PC on for the first time.
After inserting a media card in the reader, the computer attempts to boot from the media card.
Cause Solution
The inserted media card has boot capability.
On the Windows desktop, open Computer, right-click on the
corresponding drive icon, and select Eject. Then pull the card
out of the slot.
NOTE: Never remove the card when the LED is flashing
Wait a few seconds so that the operating system can
recognize the reader and the available ports, and then
recognize whatever media is inserted in the reader.
If you do not want to boot from the media card, remove it
during boot or do not select the option to boot from the
inserted media card during the boot process.

HP 100B SFF Specifications

Operating Environment

operating temperature range	10° to 35°C
nonoperating temperature range	-30° to 60°C
operating relative humidity	10-90%
nonoperating relative humidity	5-95%
operating maximum altitude	3048 m
nonoperating maximum altitude	9144 m

Power

operating voltage range	90-137Vac
rated voltage range	100-127Vac
rated line frequency	50-60Hz
power output	65 W
rated input current	1.6A @ 90 VAC

Weight and Dimensions

height	27 cm
width	10 cm
depth	34.79 cm
weight	4.8 kg
