HP 3314A Operating Manual

HOW TO USE THE 1/2 CYCLE MODE
2
.1
4
3
o
@ @
@
2
3
4
PRESET
BST
PHASE
SYM
Trigger from Channel 2 on the rialng edge.
Presets the 331 4A to a common 8t8rtlng point,
This key toggles the mode between N CYCLE and 1/2 CYCLE. The 3314A outputs
alternate 1/2 cycles whenever II trigger fa received.
ThIs PlIfsmeter seta the atarttatop phela as In N CYCLE except that the start and
stop phase alternate by 180
0
•
Used with the Phase parameter to make pulses with variable overshoot lpreahoot)
and variable rise (faR) tlmes.
1/2 Cycle Summary
Start/Stop Phaae: -90
0
to + 90°
SYM range : 6% to 96%
SWtTA INTVl: .OO2ma to 1999.
see Wavaforms 36 through 40 In the Waveform UbI'ary.
16
