HP 3314A Operating Manual

EXTERNAL MODULATION (cant)
FM Input Overload. The Reduce Input light will be ON when the AC component of the
modulating signal exceeds 2Vp-p. The DC component is inconsequential as long as
the signal peak is less than ± 10V . The Reduce Input light and .. E50 ~ .are in-
hibited while in either of the I/J Lock modes when the phase locked loop is unlock -
ed.
Voltage Controlled Oscillator
The 3314A's output frequency can be controlled over a range of + 10% to
-100% of the programmed frequency. Note that there must be C!: 100 counts in
the frequency display.
VCO I,pllt Chlraet&riltfcs. The VCO input has the following input characteristics (all
values are approximate):
Input Impedance . . . . . . . . . . . . . . . 1 OkO
Input Sensitivity 10% per Volt
(+1V = +10%)
(-10V = -100%)
Specified Linear Range + 10% to -80%
Linearity .. see VCO Specifications
3dB Bandwidth DC to 100kHz
VCO Input Overload. The Reduce Input light will be ON when the input signal exceeds
+ 1V or
-10V. The Reduce Input light and n ESO" are inhibited while in either of
the I/J lock modes when the phase locked loop is unlocked.
59
